Servo Motor Encoder Connector

Get a Price/Quote

MOQ : 100 Pieces

Servo Motor Encoder Connector Specification

Thickness
8 mm

Sealed
IP67

Cable Diameter
6-10 mm

Surface Treatment
Nickel Plated

Product Type
Encoder Connector

Material
PVC + Metal

Application
Industrial Automation

Contact Resistance
5 m

Insulation Resistance
>1000 M at 500VDC

Diameter
22 mm

Terminal Socket
Gold Plated Contacts

Style
Round

Fittings
Push-fit

Rated Voltage
250 V

Weight
30 g

Color
Black / Silver

Shock Resistance
IEC 60068-2-27 compliant

RoHS Compliance
Yes

Connector Gender
Male/Female

Mounting Type
Panel Mount

Operating Temperature
-20C to +80C

Current Rating
5A max

Wire Gauge Supported
24-18 AWG

Flame Retardant
Yes

Vibration Proof
IEC 60068-2-6 compliant

IP Rating
IP67 Waterproof Dustproof

Number of Pins
6 Pin

Servo Motor Encoder Connector Trade Information

Minimum Order Quantity
100 Pieces

Payment Terms
Cash in Advance (CID)

Supply Ability
5000 Pieces Per Month

Delivery Time
10 Days

Main Domestic Market
All India

About Servo Motor Encoder Connector

Step up your industrial automation projects with our Servo Motor Encoder Connector. This panel mount connector, decorated with venerable features and a noteworthy design, ensures a reliable connection with its 6-pin, push-fit fittings and round style. Engineered for strict environments, it comes with IP67 waterproof and dustproof ratings, shock and vibration resistance as per IEC 60068 standards, and gold-plated contacts for optimum conductivity. Flame retardant, RoHS compliant, and rated up to 5A and 250V, it's equally suited to male or female configurations. Shop now for this special wiring solution and experience unbeatable durability and performance!

Versatile Usage & Advanced Features

Designed for industrial automation, this Servo Motor Encoder Connector accommodates a range of wire gauges (24-18 AWG) and supports both male and female terminals. Its sturdy PVC and metal body ensures flame retardance, while gold-plated contacts deliver exceptional connection quality. The connector is apt for panel mounting, ensuring secure installations in decoratively demanding and venerable industrial settings. This round, push-fit connector is ideal for automated systems, robotics, and other precision control gear requiring noteworthy reliability and performance.

Certifications, Market, and Sample Policy Advantages

Engineered to be RoHS compliant and certified for IEC vibration (60068-2-6) and shock (60068-2-27) standards, our connector ensures peace of mind and reduced expenditure on replacements. Serving the Indian domestic market as a service provider, supplier, and trader, we are committed to prompt delivery and the lowest price offerings. Sample policies are available, letting you assess product quality before bulk purchase, ensuring confidence in your decision and minimizing procurement risks.

FAQ's of Servo Motor Encoder Connector:

Q: How does the Servo Motor Encoder Connector ensure safe and reliable connections in industrial automation?

A: The connector features robust panel mounting, flame retardant housing, gold-plated contacts for signal integrity, and strong insulation resistance. With IP67 rating and compliance to IEC shock and vibration standards, it delivers reliable, long-term performance in demanding automation environments.

Q: What makes this connector noteworthy in terms of durability and resistance?

A: It is constructed from high-quality PVC and metal, offers flame retardance, and has undergone stringent IEC 60068-2-6 and 60068-2-27 testing for vibration and shock. The gold-plated contacts and nickel-plated surface further enhance longevity and resistance to harsh settings.

Q: Where can the Servo Motor Encoder Connector be used?

A: This connector is perfect for industrial automation, robotics, and machinery requiring secure and waterproof electrical connections. Its design supports various wire gauges and panel mounting, making it versatile for numerous automation and motor encoding applications.

Q: What is the process for purchasing samples before bulk orders?

A: You can request samples as per our policy to evaluate product quality and suitability for your applications. Simply reach out during the quotation process to discuss sample delivery options and conditions.

Q: What benefits does the IP67 rating offer for this connector?

A: The IP67 rating guarantees complete protection against dust ingress and resistance to immersion in water, ensuring the connector remains reliable and operational in challenging industrial environments.
